Maidaid C502D Undercounter Glasswasher with Drain Pump – 500mm Basket
Maidaid C502D Undercounter Glasswasher with Drain Pump – 500mm Basket is part of the Maidaid C Range of Undercounter Glasswashers – a fully electronic machine range offering outstanding value for money.
PRODUCT FEATURES:
- 2 year warranty
- Drain pump as standard (Drain pump versions require a waste up stand for correct operation).
- Four button bright LED display with soft touch controls
- Twin traffic lights giving instant status updates & operational self-diagnostics
- Alarms menu with hi-level information retrieval
- Quick release parallel wash & rinse arm design
- Three standard cycle time options with further options available
- Cycle times can be tailored to site requirements
- Automatic self-cleaning at end of service
- Selectable energy saving mode
- Selectable thermostop ensures optimum rinse temperatures
- Patented dual flow wash pump –reducing power consumption whilst retaining wash efficiency
- Moulded wash tank for easy cleaning
- Moulded rack guide giving partial double skin
- Accurate detergent and rinse aid dosing pumps as standard
- Moulded rack guide giving partial double skin
- Maidaid Halcyon® is able to provide a site survey & installation service – please contact us to discuss. Charges will apply
SPECIFICATIONS:
- Number of standard cycles 3
- Standard cycles times Sec 70/90/180 – adjustable
- Special cycle Eco, Glass, Long
- Self-cleaning cycle Partial self drain
- Water consumption per cycle L 2
- Wash temperature °C 60 – adjustable
- Rinse temperature °C 65 – adjustable
- Feet height mm 10-20
- Rack size mm 500 x 500
- Maximum useable height mm 340
- Door opening mm 365
- Theoretical productivity Racks/h 51
- Effective productivity Racks/h 36*
- Wash tank element kW 2.1
- Boiler element kW 6
- Wash pump kW 0.47
- Tank capacity L 20
- Noise emission dB < 55
- Phase Options: Standard voltage 230V – single phase, can be supplied 3 phase – please specify at time of order.
- Single Phase: 2.6kW(13Amp),4.5kW(20Amp),6.5kW(30Amp)
- Three Phase: 6.5kW (16Amp)
- Requires to be hardwired.
EXTERNAL DIMENSIONS:
Width: 580mm
Depth: 610mm
Height: 810 + feet mm
Electrical appliances MUST be installed by a qualified electrician. Incorrect compliance to current installation legislation will lead to invalidation of warranty. Please refer to spec sheet for full electrical requirements/technical specifications
*Water treatment: To achieve good warewashing results water treatment is essential. It will help prevent calcium scaling of internal components and reduce detergent consumption. If water hardness exceeds 7° Clark (100 ppm), a water softener is recommended on all dish and glass washers, unless already built into the machine.
