DC EG50D Economy Glasswasher – 500mm Basket – 13A – With Drain Pump
The DC EG50D offers the same reliable performance as the standard EG50, with the added benefit of an integrated drain pump. Designed for busy bars, cafés and hospitality venues, it provides efficient glasswashing while solving common installation challenges where gravity drainage is not possible.
With a rapid 180-second wash cycle, energy-saving wash pump and intuitive controls, the EG50D delivers consistent, hygienic results throughout service. Supplied as a 13A plug-in unit, it allows straightforward installation while accommodating sites where the waste outlet is positioned higher than the machine’s drain outlet.
Why Buy the DC EG50D?
- Integrated drain pump for flexible site installation
- Fast 180-second wash cycle for reliable throughput
- 13A plug-in configuration
- Energy-saving wash pump reduces running costs
- Rinse thermolock ensures correct rinse temperatures
- Supplied with two 500 x 500mm glass baskets
Key Features
- 500 x 500mm basket size
- 180 second wash cycle
- 13A standard plug supply (230V / single phase)
- Integrated drain pump
- Intuitive control panel
- Programmable audio status indicator
- Rinse thermolock technology
- Energy-saving wash pump
- Improved rinse arms (30% faster initial response, 20% increased rotation speed)
- Removable anti-block wash and rinse arms
- EasyClean filters protect critical components
- Chemical auto-dosing units
- Auto-start door function
- Engineer diagnostic mode
- Single skinned construction
Technical Specifications
- Basket size: 500 x 500mm
- Cycle time: 180 seconds
- Power supply: 13 Amp (standard plug)
- Voltage: 230V / Single phase
- Dimensions: W565 x D610 x H830mm
- Supplied with 2 glass baskets
Delivery & Warranty
Fast Free UK Mainland Delivery included. For Northern Ireland, Scottish Highlands and Islands, a delivery charge will apply – please contact us for a quote.
This model is available with either a 1-year parts-only warranty or a 1-year parts & labour warranty. Please confirm your preferred option at the time of order.
Frequently Asked Questions
When do I need a drain pump?
A drain pump is required where the site waste outlet is positioned higher than the machine’s drain outlet. The EG50D includes an integrated drain pump, making it suitable for installations where gravity drainage is not possible.
Do I need a water softener?
If your site water hardness exceeds 100 ppm, a softener is strongly recommended to prevent limescale build-up and protect internal components. If you would prefer a built-in solution, consider the EG50IS (integral softener) or EG50ISD (integral softener + drain pump).
Is this model plug-in?
Yes. This version is supplied as a 13A plug-in unit for straightforward installation.
Who must install the machine?
Electrical appliances must be installed by a qualified electrician. Incorrect installation, commissioning faults or user-related issues are not covered under warranty. A warranty call-out cannot be arranged without the installing engineer’s details.
